200W Triac / ELV / MLV Dimmable LED Driver – 12V / 24V – Constant Voltage – Phase-Cut – High PF – Flicker-Free

This 200W constant voltage LED driver supports phase-cut dimming methods including TRIAC, ELV, and MLV, offering smooth 0–100% dimming performance. Designed for both residential and commercial LED lighting systems, it features a high power factor (up to 0.98), flicker-free PWM output, and robust thermal and short circuit protections. UL, cUL, FCC, and RoHS certified.

Available in both 12V (16.66A) and 24V (8.33A) outputs.

Features

• Phase-Cut Dimming Compatibility: Supports TRIAC, ELV, MLV, and reverse/forward phase dimmers

• Smooth Dimming: 0–100% flicker-free dimming with PWM output

• Waterproof Rated: Full Iron protection housing, for dry, damp & wet locations (not for submersion).


• Power Factor: High PF up to 0.98 for energy efficiency and stable performance

• Input Range: Universal 110–277VAC with built-in active PFC

• Output Options: Available in 12V (16.66A) and 24V (8.33A) – 200W total output

• Full Circuit Protection: Overload, short circuit, and over-temperature protection

• Certified & Compliant: UL / cUL / FCC / Class P / TYPE HL / SELV / RoHS / Reach

• Compact Size: 10.26" × 4.17" × 1.93" — for straightforward integration
